Hey all we now are a dealer for PLX Devices! These guys are an awesome company with an even better quality products. They have won the "Best New Product" award 6 times from SEMA! Heres a few of their products.
__________________________________________________ _________________
HDD-100 OLED

2 1/16" (52mm) Display

HIGH DEFINITION DISPLAY




DESCRIPTION:
The PLX HDD-100 is the worlds first standard size 2 1/16" (52mm) OLED automotive display. Measuring only 0.7" (18mm) thick, it can virtually be mounted anywhere. The HDD-100 is designed to fit into most aftermarket 2 1/16" (52mm) cups, and mounts for seamless integration into your vehicle. Colors can be fully customized on the fly to match your existing dash and instrument cluster.



TECHNOLOGY:

Organic Light Emitting Diode (OLED) is emerging as a leading next generation display technology. OLED technology offers several distinct advantages over the traditional liquid crystal displays (LCDs). OLEDs can be made thinner, offer more vibrant colors, and has better contrast. Its viewing angle is wider, and produces almost no polarization. Polarized sunglasses have almost no effect in viewing the projected image. This makes it an ideal display for automotive applications.





SPECIFICATIONS:

Physical Dimensions Standard 2 1/16" (52mm) x 0.7" (18mm)
Display Technology OLED 160 x 128 (20480 Pixels)
Color Depth 16 Bit
Viewing Angle 180 Degrees
Polarization None (Viewable with polarized sunglasses)
Power Consumption 0.6 Watts Typical
Cable Length 6ft (~2m)
Operating Temperature 0 - 85 Deg C
Compatible DM DM-100
__________________________________________________ ________________

DM-5 AFR

2 1/16" (52mm) Display

STANDARD DISPLAY



Available in Black Face or White Face

Must be connected to SM-AFR Module

DESCRIPTION:
The PLX DM-5 AFR is a standard size 2 1/16" (52mm) LED automotive display designed to display the values measured from the SM-AFR. Measuring only 0.7" (18mm) thick, it can virtually be mounted anywhere. The DM-5 is designed to fit into most aftermarket 2 1/16" (52mm) cups, and mounts for seamless integration into your vehicle. This is an ideal accessory for your SM-AFR module. Up to 32 can be daisy chained together in the iMFD system.

KEY FEATURES:

Affordable
2 1/16" Standard Size (52mm)
0.7" (18mm) Thick
Digital Accuracy
Must connect to SM-AFR Module

CONNECTION DIAGRAM:



3.3V from SM - Connects to the SM-AFR module's 3.3V output. This is where the DM-5 gets it's power.

Serial RX - Digital Serial input from iMFD chain

Serial TX Digital Serial output to remaining iMFD chain

*No ground connection is necessary. Ground obtained from Serial RX, TX

USES:



There are two recommended uses for the DM-5. The simple setup connects to just one SM module. This is great for stand alone gauges. The complex setup is great for monitoring several SM modules simultaneously. Looking at the above diagram. the DM-5 AFR labeled (1) automatically displays the information from SM-AFR labeled (4). The DM-5 AFR labeled (2) automatically displays the information from SM-AFR labeled (5). The DM-5 AFR labeled (3) automatically displays the information from SM-AFR labeled (6) and so on.... The DM-5 automatically "knows" where to look for the information with respect to where it is connected in the iMFD chain.

SPECIFICATIONS:

Physical Dimensions Standard 2 1/16" (52mm) x 0.7" (18mm)
Display Technology LED (3 Digit center, 16 Red, Yellow, Green Bars)
Viewing Angle 180 Degrees
Polarization None (Viewable with polarized sunglasses)
Supply Voltage 3.3V from SM Module
Power Consumption 0.25 Watts Typical
Cable Length 6ft (~2m)
Operating Temperature 0 - 85 Deg C
__________________________________________________ ________________

DM-100

DISPLAY MODULE



CAN YOUR GAUGE DO THIS?



DESCRIPTION:
The iMFD DM-100 is a mini computer designed specifically to display a wide variety of automotive information far superior to that of a standard automotive gauge. The iMFD DM-100 is designed to intercept up to 32 SM modules and to control one high definition display. Up to 32 DM-100s can be chained together in an iMFD system. The DM-100 is housed in high quality extruded aluminum designed to operate even in the most extreme conditions.

KEY FEATURES:

Multiple gauge styles (gauge, numeric, plot, 4 param, custom)
Peak and hold (4 parameters, high and low)
Intelligent warning (4 parameter comparison)
Custom gauge design
4 button remote
Daisy chain topology
Custom wallpaper upload
Automatic sensor detection
Extruded aluminum construction


CONNECTION DIAGRAM:





Connects to 12V-18V power source.
Connects to auxiliary serial application(s)
Connects to auxiliary serial application(s)
Connects to next DM in chain
Connects to previous DM or last SM in chain
Connects to compatible HDD
Connects to 4 button remote
Connect to USB port on PC for custom gauge upload



THE MENU SYSTEM:




STANDARD GAUGES:

Unlike other automotive displays on the market where the user has no choice but to view data presented only in one form, the DM-100 has the capability of displaying data in multiple forms. As seen above in the state diagram, each parameter can be viewed in a gauge style, a numeric style, a plot style, and simultaneously in the 4 parameter style. Each style offers its unique advantages.

The plot style is a unique feature in automotive displays. Now data can be viewed as a trend, instead of just it's instantaneous value. This gives the user quicker access to information without the use of a data logger.

Some additional user customizations are also available in the standard gauges. Colors can be customized, and background wallpapers of your choice can be uploaded from the PC making each gauge unique to your own taste.

CUSTOM GAUGE:

The custom gauge design is one of the many unique features found on the DM-100. In state 1-4, (seen above) the user has the absolute freedom to design your own gauge on the PC and upload it to the DM-100 via USB. You will have full control over every pixel, every pixel color and every displayed frame. It's only up to your imagination what you want to design and display to represent your automotive sensor data.



PEAK AND HOLD:

The user can set the DM-100 to remember both high or low values for each parameter. Peak values can be viewed in state 2-3 and can be reset on command at any time.



INTEGRATED WARNING:

1-4 parameters can be setup to trigger a warning condition. When a warning is triggered, the parameter's value will be displayed on the screen giving the user immediate information. Multiple warning schemes are available. This feature can prove to be extremely vital in monitoring the health of your vehicle.



TECHNOLOGY:

The DM-100 employs several new technological breakthroughs in digital design. At the core of this technology is a 32 bit CPU coupled with a PLX designed GPU (graphics processor unit). Just has high end video graphic cards are designed for PC games, the PLX GPU was designed specifically for automotive display applications, making the OLED color display possible at an affordable price. Ram, flash and USB technologies are also incorporated.



INCLUDED ITEMS:

DM-100 Module

6ft 4 button remote

4ft power wire with 2.1mm connector

1ft Serial Cable

6ft USB Cable

CD

Quick Start Guide

Firmware reflash card

HDD-100 Display

SPECIFICATIONS:

Physical Dimensions 4" x 2.875" x 1.125" (104mm x 75mm x 28mm) L x W x H
Power Consumption 1.5 Watts
Compatible HDD HDD-100
Processors Custom PLX 32 Bit Processor, Custom PLX GPU (Graphics Processor Unit)
Operating Temperature 0 - 85 Deg C
Operating Voltage 10V-18V
Automatic Sensor Detection YES
Human Interface 4 Button Remote
PC Interface USB 2.0
# Sensor Modules 1-32
Firmware Upgradeable Yes
Enclosure Extruded Aluminum
__________________________________________________ _________________

SENSOR MODULES (SM)

SM-AFR PLX Wideband O2 Controller for accurate Air/Fuel Ratio Measurements



SM-EGT Exhaust Gas Temperature (K-Type T.C.)



SM-FluidTemp Water Temp, Aftercooler Temp, Transmission Temp, Oil Temp



SM-Vac/Boost 3 Bar Vacuum-Boost


__________________________________________________ ________________
COMING SOON!!!

DISPLAY MODULES (DM)
Coming Soon DM-5 EGT 2 1/16" (52mm) Standard LED Exhaust Gas Temperature Gauge
Coming Soon DM-5 Vac/Boost 2 1/16" (52mm) Standard LED Vac/Boost Gauge
Coming Soon DM-5 FluidTemp 2 1/16" (52mm) Standard LED Fluid Temp Gauge


SENSOR MODULES (SM)
Coming Soon SM-FuelPressure Fuel Pressure
Coming Soon SM-OilPressure Oil Pressure
Coming Soon SM-OBD2/CAN Obtains sensor information from vehicle's OBD2 port (RPM, MPH, Timing, Coolant Temp, and many more...)
Coming Soon iMFD Data Logger Features data record, playback, start, stop, pause, PC connectivity and data logging software for analysis
