fastspoolingsx

iTrader: (1)

I am interested in running a survey as to those running manley cranks and having issues with cracking. Specifically 2.3 stroker cranks, but interested in all strokes. I have been seeings a few pop up. I am nearing block assembly and I want to be certain before putting it in the block.

roni4g63

iTrader: (1)

Manely in general has been manufacturing from china for a while, quality control will not be as high as a USA made part, this goes for the billet pieces aswell.

100mm cranks are know to crack, atleast the aftermarket ones.

I've heard of a 88mm manely billet crack aswell.

I've personally ran the 100mm billet in my car without issues. either stick with Oem 88mm, eagle 94mm and go with a 2.0 or just use a good OEM 100mm.

The best option is the 2.2, you get a very good rod/stroke ratio and can rev it up to 9-9.5k with supporting valvetrain and you also get the increase displacement.

if you are already assembling, yes the manely 100m cranks like are said are known to crack.

fastspoolingsx

iTrader: (1)

Thanks for the reply. I was leaning towards a 2.2 Everything is still boxed up. I do have a 2.4 block that is good.

4b11slayer

Every time i read a thread here about manley its a horror story.

fastspoolingsx

iTrader: (1)

Thank you. I think i will be switching my plans.

EvolTweetyBird

Here's the Manley out of Ronnie's (RS Motors) built engine, actually I think it was the second one to fail.
We loaned him our spare engine so he,Brandon,and Andy could finish up The One Lap of America competition.

fastspoolingsx

iTrader: (1)

This is some serious bull. lol How are the gsc kits?

4b11slayer

Why dont you do a 2.0 long rod and use a factory crank.

bboypuertoroc

iTrader: (17)

There's been PLENTY of cracked Manley cranks. Most builders won't even touch them anymore.

LetsGetThisDone

iTrader: (1)

Manley is prone to cranking, stay away. Only reason the turbo tuff rods are "good" is they weigh a ton, all the extra material makes them last.


If you want a good setup, Eagle cranks do very well. I would go with stock or 94mm stroke.

fastspoolingsx

iTrader: (1)

Well I will report back if I find another kit to go with.

dr_latino999

iTrader: (12)

Ok, maybe they changed it up, but I've been using my 94mm billet crank since 2014 with no issues. Just passed 30K+ miles.

JRally

Stay away from Manley Forged. Billet is debatable.

fastspoolingsx

iTrader: (1)

So who needs a 100mm stroke forged crank? Lol
manley says this crank usually let's go after 500hp and twin disk.

JRally

I broke at 430whp and an ACT XTSS
